TECHNICAL SPECIFICATIONS:
Main Station :
Interface: N-type antenna interface x2, Dc input Canon N-port x1, 4-wire access Canon N-port x12-wire accessCanon port x1, USB interface x1, cascaded Canon N-port x1 3/8 installation threaded holePower supply method: NP-F: 6.5V16V input; POE power supply: 44~57V DC input
Power consumption: less than 9W
Dimensions:(L*W*H):180.4*48.5*242.5mm
Net weight: approximately 1500g
Working distance: 400 meters
Frequency band: 1.9GHz
Modulation mode: GFSK/DBPSK
Transmit power: <128mW
Bandwidth: 1.728MHz
Temperature range: 0-40C (working);-20-+60C (storage)
Headphone output frequency response: 300Hz~7KHZTwo-wire output frequency response: 300Hz~7KHZ
Signal-to-noise ratio: >50dB
Distortion: <1.5%
Sampling rate: 1 6bit
Microphone sensitivity: -56+5dBV
Headphone speaker sensitivity:-95+3dBSP
Headphone output volume amplitude:>110dBSPl
Interface: SMA antenna interface x2, 8-core Lemo headphone socket x1, 3.5mm headphone socket x1,USB Type-C port x1
Power supply: 1500mAh polymer lithium battery (7 hours of continuous use)
Power consumption: Less than 0.8W
Dimensions(L*W*H):65*26*105mm
Net weight: Approximately 200g
Working distance: 400 meters
Frequency band: 1.9GHz
Modulation mode: GFSK/DBPSK
Transmit power: n/a
Receiver sensitivity:<-93dBm
Bandwidth:1.728MHz
Temperature range: 0-+40°C (working);-20-+60C (storage)
MORE to DOWNLOAD from PRODUCT CATALOGUE ABOVE
