3P XLR Male/Female Connector.
New design of latch lock.
Unique cage design of contacts.
Chuck type strain relief makes assembly easier and faster.
Internal thread on the boots. 5 colored rings are available.
Contact resistance: < 0.01ฮฉ
Insulation resistance: > 2000ฮฉ
Dielectric strength: AC250V 50Hz
Lifetime>1’200 mating cycles
Temperature range:-30โ to + 80โ
All parts comply with SGS, certificate is available
Products comply with ROHS
Products with CE Recognized
